SCSFExport scsf_StudyAngle(SCStudyInterfaceRef sc)
{
  SCSubgraphRef Angle = sc.Subgraph[0];
  SCSubgraphRef ZeroLine = sc.Subgraph[1];

  SCInputRef InInputData = sc.Input[0];
  SCInputRef InLength = sc.Input[1];
  SCInputRef InValuePerPoint = sc.Input[2];
  SCInputRef InSkipCalculationAtStartOfTradingDay = sc.Input[3];

  if (sc.SetDefaults)
  {
    // Set the configuration and defaults

    sc.GraphName = "Study Angle";
    sc.AutoLoop = 1;

    //During development set this flag to 1, so the DLL can be modified. When development is completed, set it to 0 to improve performance.
    sc.FreeDLL = 0;

    Angle.Name = "Angle";
    Angle.DrawStyle = DRAWSTYLE_LINE;
    Angle.PrimaryColor = RGB(0, 255, 0);
    Angle.DrawZeros = false;

    ZeroLine.Name = "Zero Line";
    ZeroLine.DrawStyle = DRAWSTYLE_LINE;
    ZeroLine.PrimaryColor = RGB(255, 0, 255);
    ZeroLine.DrawZeros = true;

    InInputData.Name = "Input Data";
    InInputData.SetInputDataIndex(0);

    InLength.Name = "Length";
    InLength.SetInt(10);
    InLength.SetIntLimits(1, MAX_STUDY_LENGTH);

    InValuePerPoint.Name = "Value Per Point";
    InValuePerPoint.SetFloat(1.0f);

    InSkipCalculationAtStartOfTradingDay.Name = "Skip Calculation at Start of Trading Day";
    InSkipCalculationAtStartOfTradingDay.SetYesNo(false);

    return;
  }

  int Length = InLength.GetInt();

  sc.DataStartIndex = Length;

  if (InValuePerPoint.GetFloat() == 0.0f)
    InValuePerPoint.SetFloat(0.01f);

  int &r_IndexOfNewDay = sc.GetPersistentInt(1);
  if (sc.IsFullRecalculation && sc.Index == 0)
    r_IndexOfNewDay = -1;

  // Do data processing
  bool SkipCalculation = false;
  if (InSkipCalculationAtStartOfTradingDay.GetYesNo())
  {
    if (sc.IsNewTradingDay(sc.Index))
    {
      r_IndexOfNewDay = sc.Index;
    }

    SkipCalculation = r_IndexOfNewDay == sc.Index || (sc.Index - Length) < r_IndexOfNewDay;
  }

  if (!SkipCalculation)
  {
    SCFloatArrayRef InData = sc.BaseData[InInputData.GetInputDataIndex()];

    float BackValue = InData[sc.Index - Length];
    float CurrentValue = InData[sc.Index];

    float PointChange = (CurrentValue - BackValue) / InValuePerPoint.GetFloat();

    Angle[sc.Index] = (float)(atan2((double)PointChange, (double)Length) * 180.0 / M_PI);
  }
  else
  {
    Angle[sc.Index] = 0;
  }
}
