#include "sierrachart.h"

SCDLLName("StudyAngleReset");


SCSFExport scsf_StudyAngle(SCStudyInterfaceRef sc)
{
  SCSubgraphRef Angle = sc.Subgraph[0];
  SCSubgraphRef ZeroLine = sc.Subgraph[1];

  SCInputRef InInputData = sc.Input[0];
  SCInputRef InLength = sc.Input[1];
  SCInputRef InValuePerPoint = sc.Input[2];
  SCInputRef ResetAtSessionStart = sc.Input[3];

  if (sc.SetDefaults)
  {
    // xx

    sc.GraphName = "Study Angle";
    sc.AutoLoop = 1;

    // xx
    sc.FreeDLL = 0;

    Angle.Name = "Angle";
    Angle.DrawStyle = DRAWSTYLE_LINE;
    Angle.PrimaryColor = RGB(0,255,0);
    Angle.DrawZeros= false;

    ZeroLine.Name = "Zero Line";
    ZeroLine.DrawStyle = DRAWSTYLE_LINE;
    ZeroLine.PrimaryColor = RGB(255,0,255);
    ZeroLine.DrawZeros= true;

    InInputData.Name = "Input Data";
    InInputData.SetInputDataIndex(0);

    InLength.Name = "Length";
    InLength.SetInt(10);
    InLength.SetIntLimits(1,MAX_STUDY_LENGTH);

    InValuePerPoint.Name = "Value Per Point";
    InValuePerPoint.SetFloat(1.0f);

    ResetAtSessionStart.Name = "Reset at Start of Trading Day";
    ResetAtSessionStart.SetYesNo(0);

    return;
  }

  int Length = InLength.GetInt();

  sc.DataStartIndex = Length;

  if (InValuePerPoint.GetFloat() == 0.0f)
    InValuePerPoint.SetFloat(0.01f);

  SCDateTime NextSessionStart = sc.GetTradingDayStartDateTimeOfBar(sc.BaseDateTimeIn[sc.DataStartIndex - 1]) + 1*DAYS;

  if (sc.DataStartIndex == 0)
  {
    Angle[0] = 0;
  }

  for (int Index = max(sc.DataStartIndex, 1); Index < sc.ArraySize; Index++)
  {
    if (ResetAtSessionStart.GetYesNo() != 0)
    {
      SCDateTime IndexDateTime = sc.BaseDateTimeIn[Index];
      SCDateTime LengthDateTime = sc.BaseDateTimeIn[Index - Length];

      if (IndexDateTime >= NextSessionStart || (LengthDateTime < NextSessionStart - 1 * DAYS || LengthDateTime >= NextSessionStart))
      {
        Angle[Index] = 0;

        NextSessionStart = sc.GetTradingDayStartDateTimeOfBar(IndexDateTime) + 1*DAYS;
      }
      else
      {
        SCFloatArrayRef InData = sc.BaseData[InInputData.GetInputDataIndex()];

        float BackValue = InData[Index - Length];
        float CurrentValue = InData[Index];

        float PointChange = (CurrentValue - BackValue) / InValuePerPoint.GetFloat();

        Angle[Index] = (float)(atan2((double)PointChange, (double)Length) * 180.0 / M_PI);
      }
    }
    else
    {

          SCFloatArrayRef InData = sc.BaseData[InInputData.GetInputDataIndex()];

          float BackValue = InData[Index - Length];
          float CurrentValue = InData[Index];

          float PointChange = (CurrentValue - BackValue) / InValuePerPoint.GetFloat();

          Angle[Index] = (float)(atan2((double)PointChange, (double)Length) * 180.0 / M_PI);

    }
  }
}

for (int Index = max(sc.DataStartIndex, 1); Index < sc.ArraySize; Index++)
